SX25 (25 tonne) Load Moving System

SX25 (25 tonne) Load Moving System

SX25 (25 tonne) Load Moving System

SX25 (25 tonne) Load Moving System

Carrying capacity of system: 25,000 kgs

Wheels (Blue composite): 48 off x 82mm dia x 48mm

Turntable diameter: 180mm

Overall loading height: 110mm

Rear width adjustment: 720mm to 1500mm

Load area of rear skates: 2 off x 360mm x 176mm

Total boxed weight: 136kgs

Towing eye as standard: Yes
